CLASSIC 513 Gradient Heat Seal Tester is professionally designed for the determination of heatsealability of plastic films, composite films, coated paper, and other sealing films under certain sealing speed, pressure and 5 different temperatures. The heatsealability of heat sealing materials would be greatly affected by the factors of melting point, thermal stability, fluidity and thickness. The optimal heatsealability parameters can be obtained accurately and efficiently through this instrument.


Technical Specifications

Specifications	CLASSIC 513
Sealing Temperature	Room temperature ~ 250°C
Dwell Time	0.5~999.9 s
Temperature Accuracy	±2°C
Temperature Resolution	0.1°C
Temperature Gradient	≤20°C
Gas Supply Pressure	0.1 MPa ~ 0.7 MPa (outside of supply scope)
Port Size	Φ8 mm PU Tubing
Sealing Area	40 mm x 10 mm
Number of Sealing Jaws	10 (5 x 2 groups)Note1
Instrument Dimension	576 mm (L) x 430 mm (W) x 510 mm (H)
Power Supply	220VAC 50Hz / 120VAC 60Hz
Net Weight	72 kg
